Daikin FXCQ-A - 2 Specifications; Technical Specifications

3
1
2
• VRV Systems • Indoor Unit
3
• Indoor Unit • 2-way blow ceiling mounted cassette • FXCQ-A
2 Specifications
Standard Accessories : Insulation piping cover for drain piping;
Standard Accessories : Screws;
Standard Accessories : Clamps;
Standard Accessories : Sealing material;
Standard Accessories : Washer clamp;
Standard Accessories : Joint insulating material;
Standard Accessories : Drain hose;
Standard Accessories : Clamp metal;
Standard Accessories : Washer for hanger bracket;
Standard Accessories : Installation pattern;
2-1 Technical Specifications FXCQ20A FXCQ25A FXCQ32A FXCQ40A FXCQ50A FXCQ63A FXCQ80A FXCQ125A
Cooling capacity Nom. kW 2.2 (1) 2.8 (1) 3.6 (1) 4.5 (1) 5.6 (1) 7.1 (1) 9.0 (1) 14.0 (1)
Heating capacity Nom. kW 2.5 (2) 3.2 (2) 4.0 (2) 5.0 (2) 6.3 (2) 8.0 (2) 10.0 (2) 16.0 (2)
Power input - 50Hz Cooling Nom. kW 0.031 0.039 0.041 0.059 0.063 0.090 0.149
Heating Nom. kW 0.028 0.035 0.037 0.056 0.060 0.086 0.146
Casing Material Galvanised steel plate
Dimensions Unit Height mm 305
Width mm 775 990 1,445
Depth mm 620
Weight Unit kg 19 22 25 33 38
Decoration panel Model BYBCQ40HW1 BYBCQ63HW1 BYBCQ125HW1
Colour Fresh white (6.5Y 9.5/0.5)
Dimensions Height mm 55
Width mm 1,070 1,285 1,740
Depth mm 700
Weight kg 10 11 13
Heat exchanger Rows Quantity 2
Fin pitch mm 1.2
Face area m² 0.334 0.218 0.320
Stages Quantity 16
Heat exchanger 2 Face area m² - 0.218 0.320
Fan Type Turbo fan
Air flow rate - 50Hz Cooling High m³/min 10.5 11.5 12 15 16 26 32
Nom. m³/min 9 9.5 10.5 13 14 22.5 27.5
Low m³/min 7.5 8 8.5 10.5 11.5 18.5 22.5
Fan motor Quantity 1 2
Model QTS36A15M
Output High W 46 106 46 106
Drive Direct drive
Fan motor 2 Drive - Direct drive
Output High W - 46.000 106.000
Sound pressure level Cooling High dBA 32.0 34.0 36.0 37.0 39.0 42.0 46.0
Nom. dBA 30.0 31.0 32.0 33.0 35.0 37.0 38.0 42.0
Low dBA 28.0 29.0 30.0 31.0 32.0 33.0 38.0
Heating High dBA 32.0 34.0 36.0 37.0 39.0 42.0 46.0
Nom. dBA 30.0 31.0 32.0 33.0 35.0 37.0 38.0 42.0
Low dBA 28.0 29.0 30.0 31.0 32.0 33.0 38.0
Refrigerant Type R-410A
Control Electronic expansion valve
Piping connections Liquid Type Flare connection
OD mm 6.35 9.52
Gas Type Flare connection
OD mm 12.7 15.9
Drain VP25 (O.D. 32 / I.D. 25)
Temperature control Microprocessor thermostat for cooling and heating
Air filter Type Resin net with mold resistance
Safety devices Item 01 Fuse
