Specifications EDUS39-900-F10
4 FXMQ-MF
2. Specifications
Notes:
1 Nominal cooling capacities are based on the following conditions:
Outdoor temperature: 91°FDB, 82°FWB (68%RH)
Discharge set temp: 64°FDB
Equivalent ref. piping: 25ft (Horizontal)
2 Nominal heating capacities are based on the following conditions:
Outdoor temperature: 32°FDB, 27°FWB (50%RH)
Discharge set temp: 77°FDB
Equivalent ref. piping: 25ft (Horizontal)
3 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
4 Air filter is not standard accessory, but please mount it in the duct system of the suction side.
Select its duct collection efficiency (gravity method) 50% or more.
5 Within the range that the total capacity of indoor units is 50 to 100%, it is possible to connect to the outdoor unit.
6 This equipment cannot be incorporated into the remote group control of the VRV III system.
Model FXMQ48MFVJU FXMQ72MFVJU FXMQ96MFVJU
1 Cooling Capacity Btu/h 48,000 72,000 96,000
2 Heating Capacity Btu/h 30,000 47,000 59,000
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) in. 18’1/2’’×29’1/4’’×43’5/16’’ 18’1/2’’×54’3/8’’×43’5/16’’ 18’1/2’’×54’3/8’’×43’5/16’’
Coil (Cross
Fin Coil)
Rows×Stages×Fin
Pitch
in. 3×26×13 3×26×13 3×26×13
Face Area ft² 3.01 7.00 7.00
Fan
Model D13/4G2DA1 D13/4G2DA1 D13/4G2DA1
Type Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output ×
Number of Units
W 380×1 380×1 380×1
Air Flow Rate (H/L) cfm 635 988 1,236
External Static
Pressure 4
in. WG 0.88 0.96 1.03
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat for Cooling
and Heating
Microprocessor Thermostat for Cooling
and Heating
Microprocessor Thermostat for Cooling
and Heating
Sound Absorbing Thermal Insulation Material Glass Fiber Glass Fiber Glass Fiber
Air Filter 4 4 4
Piping
Connections
Liquid Pipes in.
3/8
(Flare Connection)
3/8
(Flare Connection)
3/8
(Flare Connection)
Gas Pipes in.
5/8
(Flare Connection)
3/4
(Brazing Connection)
7/8
(Brazing Connection)
Drain Pipe PS1B (female thread) PS1B (female thread) PS1B (female thread)
Machine Weight (Mass) Lbs 190 271 271
Safety Devices
Fuse
Thermal Protector
for Fan Motor
Fuse
Thermal Protector
for Fan Motor
Fuse
Thermal Protector
for Fan Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Standard Accessories
Operation Manual, Installation Manual,
Sealing Pads, Screws, Clamps.
Operation Manual, Installation Manual,
Sealing Pads, Connection Pipes,
Screws, Clamps.
Operation Manual, Installation Manual,
Sealing Pads, Connection Pipes,
Screws, Clamps.
Connectable Outdoor Units 5,6 R-410A P series R-410A P series R-410A P series
Draw
ing No. C : 3D065463 C : 3D065463 C : 3D065463
