• Indoor Unit • HXHD-A
2
• VRV Systems • HXHD-A
4
2 Specifications
Notes
(1) EW 40°C; LW 45°C; Dt 5°C; ambient conditions: 7°CDB/6°CWB
(2) For water Dt 5°C
(3) Sound level is valid in free field condition because it is measured in a semi-anechoic room. Measured value under actual installation conditions will be higher due to environmental
noise and sound reflections.
(4) Values are sound pressure values measured at all sides (front, back, left, right, top) at 1m distance. The values do not occur simultaneously on all mentioned sides.
(5) Sound levels are measured at: EW 55°C; LW 65°C
(6) Sound levels are measured at: EW 70°C; LW 80°C
(7) In accordance with EN/IEC 61000-3-11, it may be necessary to consult the distribution network operator to ensure that the equipment is connected only to a supply with Zsys
(system impedance) ≤ Zmax
(8) EN/IEC 61000-3-11: European/international technical standard setting the limits for voltage changes, voltage fluctuations and flicker in public low-voltage supply systems for
equipment with rated ≤ 75A
(9) EN/IEC 61000-3-12: European/international technical standard setting the limits for harmonic currents produced by equipment connected to public low-voltage system with input
Water side Heat
exchanger
Water flow rate Min. l/min 5
Heating Nom. l/min 40.1 (2)
Heating Type Plate heat exchanger
Quantity 1
Plates Quantity 72
Material AISI 316
Water volume l 2.2
Insulation material Felt type
Water filter Diameter perforations mm 1
Material Brass
Cascade compressor Quantity 1
Motor Type Hermetically sealed swing compressor
Starting method Direct on line
Installation place Indoor
2-2 Electrical Specifications HXHD125A
Power supply Phase 1~
Frequency Hz 50
Voltage V 220-240
Voltage range Min. % -10
Max. % 6
Current Zmax Text 0.46
Minimum Ssc value kVa 1,459
Maximum running
current
Heating A 16.5
Recommended fuses A 20
Wiring connections For power supply Quantity 2G
Type of wires Select diameter and type according to national and local regulations
Benefit kWh rate
power supply
installations
Quantity 2G+2G
Type of wires Select diameter and type according to national and local regulations
For power supply
multi tenant
Quantity 2G
Remark Select diameter and type according to national and local regulations
For connection with
outdoor unit
Quantity 2
Remark F1 + F2
Power supply intake Both indoor and outdoor unit
Multi tenant Power supply Voltage V 24
Voltage
range
Min. % -20
Max. % 20
Current Maximum running
current
A1
Recommended
fuses
A3.15
2-1 Technical Specifications HXHD125A
