IM 893-10 • ROOFPAK SINGLEZONE UNITS 144 www.DaikinApplied.com
rePlaCeMenT ParTs lIsT
rePlaCeMenT ParTs lIsT
Component Designation Description Daikin Part Number
MCB Main Controller—must be programmed (unit GO# required) 193407301
NA Connector, Extension I/O Direct Connect 193409701
NA Terminal Block, MCB–2 Pole 193410302
NA Terminal Block, MCB–3 Pole 193410303
NA Terminal Block, MCB–5 Pole 193410305
NA Terminal Block, MCB–6 Pole 193410306
NA Terminal Block, MCB–7 Pole 193410307
NA Terminal Block, MCB–8 Pole 193410308
EXP A Expansion Module—Condenser/Energy Recovery 193407501
EXP B Expansion Module—Heat 193407501
EXP C Expansion Module—Specials 193407501
NA Terminal Block, MCB–2 Pole 193410302
NA Terminal Block, MCB–3 Pole 193410303
NA Terminal Block, MCB–7 Pole 193410307
NA Terminal Block, MCB–8 Pole 193410308
CCB1 Auxiliary Cooling Control Board (DX Circuit #1 or generic condenser) 112026101 (replaces 106102701)
CCB2 Auxiliary Cooling Control Board (DX Circuit #2) 112026101 (replaces 106102701)
EHB1 Auxiliary Electric Heat Control Board 112026101 (replaces 106102701)
ERB1 Auxiliary Energy Recovery Control Board 112026101 (replaces 106102801)
— RS-485 Communication Module (for Auxiliary Control Boards) 060006202
— Standoffs for mounting RS-485 Communication Module (PN 060006206) onto Auxiliary Control Board (PN 112026101) 048166707
— Keypad/Display 060006301
— Keypad-Main Control Board Cable 111044601
ZNT1
Zone Temperature Sensor with Tenant Override 111048101
Zone Temperature Sensor with Tenant Override & Remote Setpoint Adjustment (SCC units only) 111048102
DAT Discharge Air Temperature Sensor (50 ft cable length-eld cut to length) 060004705
EFT Entering Fan Air Temperature Sensor (50 ft cable length-eld cut to length) 060004705
OAT Outside Air Temperature Sensor (50 ft cable length-eld cut to length) 060004705
RAT Return Air Temperature Sensor (50 ft cable length-eld cut to length) 060004705
SPS1 Static Pressure Sensor: Duct, No. 1 049545007
SPS2
Static Pressure Sensor: Duct, No. 2 049545007
Static Pressure Sensor: Building (Space) Pressure 049545006
T2 Transformer: 115/24 V (ac) 060004601
T3 Transformer: 115/24 V (ac) 060004601
T9 Transformer: 115/24 V (ac) 060630801
HUM1
Humidity Sensor: Wall Mount 067294901
Humidity Sensor: Duct Mount 067295001
PC5 Dirty Filter Switch: First Filter Section 065493801
PC6 Dirty Filter Switch: Final Filter Section 065493801
PC7 Airow Proving Switch 060015801
DHL Duct High Limit Switch 065493801
OAE
Enthalpy Control: Electromechanical 030706702
Enthalpy Control: Electronic (Used with RAE) 049262201
RAE Return Air Enthalpy Sensor (Used with Electronic OAE) 049262202
SD1 Smoke Detector: Supply Air 049025001
SD2 Smoke Detector: Return Air 049025001
— BACnet MS/TP Communication Module (RS485) 090016710
— BACnet/IP Communication Module (Ethernet Cable 10BASET) 090016709
— LonMark Space Comfort Controller (SCC) Communication Module 090016712
— LonMark Discharge Air Controller (DAC) Communication Module 090016711
— 5 V (dc) Power Supply 111049601
— Serial Port Ribbon 111047201
— MCB Battery BR2325
— MCB Connector Repair Kit 300036605
— Power Disconnect Switch 033696300
— 18 in. Lamp Holder 205484001
— 24 in. Lamp Holder 205484101
— 36 in. Lamp Holder 205484201
— Hard Wire Module 205485501
— 18 in. Lamp 205484501
— 24 in. Lamp 205484601
— 36 in. Lamp 205484701
