RCS Equipment Warranty Registration Form (continued)
13F-4155 (02/16) 2
Select Yes or No. If not applicable to the type of unit, select N/A.
I. INITIAL CHECK
A. Is any shipping damage visible? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
B. Tightened all setscrews?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
C. Have the shipping spacers been removed from the compressor springs and have the neoprene
spacers been installed on each compressor mounting bolt? . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
D. Electrical service corresponds to unit nameplate? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
Volts _____________ Hertz _____________ Phase _____________
E. Is the main disconnect adequately fused and are fuses installed? . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
F. Are crankcase heaters operating, and have they been operating 24 hours prior to start-up? . . . . . . . . . Yes No N/A
G. Are all electrical power connections tight? (Check compressor electrical box.) . . . . . . . . . . . . . . . . Yes No N/A
H. Has the eld piping been piped per ASHRAE recommendations?. . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
II. START-UP COMPRESSOR OPERATION
A. Has each circuit been eld leak tested?
Circuit #1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
Circuit #2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
B. Refrigerant charge per circuit: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Circuit 1 ________ Circuit 2 ________
C. Are compressors rotating in the right direction?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
D. Do condenser fans rotate in the right direction? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
E. Ambient temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . _____________°F
F. Compressor lockout timers function? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
G. FanTrol functions: . . . . . . . . . . . . . . . . . . . . . TC12 _____________ TC13 _____________ TC14 _____________
H. Does unit start up and perform per sequence of operation? . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
III. PERFORMANCE DATA
A. Compressor voltage across each phase: . . . . . . . L1–2_____________ V L2–3 _____________ V L1–3 _____________ V
B. Compressor amperage of fully loaded compressor . Compressor #1 — Phase 1________ Phase 2 ________ Phase 3 _______
Compressor #2 — Phase 1________ Phase 2 ________ Phase 3 _______
Compressor #3 — Phase 1________ Phase 2 ________ Phase 3 _______
Compressor #4 — Phase 1________ Phase 2 ________ Phase 3 _______
Compressor #5 — Phase 1________ Phase 2 ________ Phase 3 _______
Compressor #6 — Phase 1________ Phase 2 ________ Phase 3 _______
C. Low pressure cut-out: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Circuit 1 __________ psig Circuit 2 __________ psig
Low pressure cut-in: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Circuit 1 __________ psig Circuit 2 __________ psig
D. High pressure cut-out: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Circuit 1 __________ psig Circuit 2 __________ psig
E. Discharge pressure, one compressor: . . . . . . . . . . . . . . . . . . . . . Circuit 1 __________ psig Circuit 2 __________ psig
Discharge pressure, fully loaded, 2–3 compressors: . . . . . . . . . . . . . Circuit 1 __________ psig Circuit 2 __________ psig
IM 962-4 • AIR-COOLED SPLIT SYSTEM CONDENSERS 32 www.DaikinApplied.com
