Daikin RKC25PVMV - Remove Fan Motor

Si001560EB Outdoor Fan / Fan Motor
Removal Procedure 5
4 Remove the screw, and
then the fan motor
fixing frame.

When reassembling, fit the 2
lower hooks into the bottom
frame.
5 Unfasten the 2 hooks
on the fan motor fixing
frame and release the
fan motor lead wire.
6 Remove the 3 screws,
and then the fan motor.
Step Procedure Points
Fan motor fixing frame
(R22387)
(R10460)
Fan motor lead wire
Hook
(R22388)
Fan motor
(R22389)
