SiENBE04-808_A FTXS20/25/35/42/50G2V1B
System Configuration 64
2.2 Auto Dry Cool Heat Fan Operation
The air conditioner operates with the operation mode of your choice.
From the next time on, the air conditioner will operate with the same
operation mode.
To start operation
1. Press “MODE selector button” and
select a operation mode.
• • Each pressing of the button advances
the mode setting in sequence.
: AUTO
: DRY
: COOL
: HEAT
: FAN
Cooling only model
Heat pump model
2. Press “ON/OFF button” .
• The OPERATION lamp lights up.
To stop operation
3. Press “ON/OFF button” again.
• Then OPERATION lamp goes off.
To change the temperature setting
4. Press “TEMPERATURE adjustment
button”.
1
5
2, 3
4
DRY or FAN mode AUTO or COOL or HEAT mode
The temperature setting is not variable. Press “ ” to raise the temperature and press
“ ” to lower the temperature.
Set to the temperature you like
C
To Next Page
