1) ALL SPECIFICATIONS ARE SUBJECT TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE
NO. PARTS DESCRIPTION
1 ASSY.,TOP / BACK PANEL W/INS
2 ASSY., COIL HOLDER L W/INS
3 ASSY., COIL (FLARE JOINT) 13 ASSY, BOTTOM PANEL W/INS
4 FAN, DECK 14 ASSY, TER. BOX (W/O O/LOAD STARTER)
5 MOTOR (HL - M504ZM)
15
ASSY, FRONT FRAME (W/O O/LOAD STARTER)
6 ASSY, BLOWER HOUSING 04
7 BRACKET, FAN DECK
8 ASSY., COIL HOLDER R W/INS
9 BRACKET L , HANGER W/PAINT
10
16 ASSY, LED FRONT FRAME (W/O PAINT)
Model : FH15CBV1L, FH15CBV1M
17 ASSY, SIDE PANEL (W/O S/PAINT)
18 HOOK
19 HANDSET, LCD (G2-E)
20 ASSY, AIR RET GRILLE, 390M
BOLT, DOME HEAD HEX.
11 BRACKET R, HANGER W/PAINT
12 ASSY, DRAIN PAN W/INS
PARTS DESCRIPTIONNO.
