1
Contents
Safety Considerations .................................... 1
Accessories ..................................................... 3
Installation Space Requirements .................. 4
Precautions for Selecting a Location ........... 4
Precautions on Installation ............................ 5
Outdoor Unit Installation Diagram ................ 5
Selecting a Location for Installation of the
Indoor Units ..................................................... 6
Outdoor Unit Installation ................................ 7
1. Installing the outdoor unit ............................................ 7
2. Drain work .................................................................. 7
3. Flaring the pipe end ..................................................... 7
4. Refrigerant piping ........................................................ 8
5. Pressure test and evacuating system .......................... 9
Wiring ............................................................... 10
Pump Down Operation ................................... 12
Trial Operation and
Testing ........................... 12
1. Trial operation and testing ........................................... 12
2. Test items .................................................................... 12
Safety Considerations
Refer also to the General Safety Considerations in the
separate booklet.
Read the precautions in this manual
carefully before operating the unit.
Refrigerant
Safety Group
A2L
This appliance is lled with R32.
Read these Safety Considerations for Installation carefully before
installing an air conditioner or heat pump. After completing the installation,
make sure that the unit operates properly during the startup operation.
Instruct the user on how to operate and maintain the unit.
Inform users that they should store this installation manual
with the operation manual for future reference.
Always use a licensed installer or contractor to install this product.
Improper installation can result in water or refrigerant leakage,
electric shock, re, or explosion.
Meanings of DANGER, WARNING, CAUTION, and NOTE Symbols:
DANGER
...........
Indicates an imminently hazardous
situation which, if not avoided, will
result in death or serious injury.
WARNING
.........
Indicates a potentially hazardous
situation which, if not avoided, could
result in death or serious injury.
CAUTION
..........
Indicates a potentially hazardous
situation which, if not avoided, may result
in minor or moderate injury. It may also
be used to alert against unsafe practices.
NOTE
................
Indicates situations that may result
in equipment or property damage
accidents only.
DANGER
• Refrigerant gas is heavier than air and replaces oxygen.
A massive leak can lead to oxygen depletion, especially
in basements, and an asphyxiation hazard could occur
leading to serious injury or death.
• Do not ground units to water pipes, gas pipes, telephone
wires, or lightning rods as incomplete grounding can
cause a severe shock hazard resulting in severe injury or
death. Additionally, grounding to gas pipes could cause a
gas leak and potential explosion causing severe injury or
death.
• If refrigerant gas leaks during installation, ventilate the
area immediately. Refrigerant gas may produce toxic gas
if it comes into contact with re. Exposure to this gas could
cause severe injury or death.
• After completing the installation work, check that the
refrigerant gas does not leak throughout the system.
• Do not install unit in an area where ammable materials
are present due to risk of explosions that can cause
serious injury or death.
• Safely dispose all packing and transportation materials
in accordance with federal/state/local laws or ordinances.
Packing materials such as nails and other metal or
wood parts, including plastic packing materials used for
transportation may cause injury or death by suffocation.
• All possible ignition sources, including cigarette smoking,
should be kept sufciently far away from the site of
installation, repairing, removing and disposal.
The pictures in this document are for illustrative purposes only.
*
1
The drain socket and drain caps are not included with product. They are available for separate purchase.
*
2
When performing work using the areless joints (accessory), refer to the instruction manual for areless joints.
Product information, manuals, etc., are
available from the link below.
Web site:
https://daikinac.com/
