Removal of Outer Panels / Fan Motor
Si001067
4
Remov
al Procedure
5
Remove the 8 screws
of t
he front
panel.
6
Unfast
en the hooks.
Pull
and remove the
front
panel.
The fr
ont panel
has 4 hooks.
Step
Procedure
Points
(R11825)
F
ront panel
(R13505)
Hook
5
7
