Daikin RYN-E3V1B User Manual

3
1
2
• Split Sky Air • Outdoor Units
2
• Outdoor Units • R-410A • RYN-E3V1B
2 Specifications
2-1 NOMINAL CAPACITY AND
NOMINAL INPUT RYN50E3V1B RYN60E3V1B
For
combination
indoor units +
outdoor units
Indoor Units FTYN50EV1B FTYN60EV1B
Cooling
capacity
Standard kW 5.0 6.0
Heating
capacity
Standard kW 5.8 7.0
Nominal input Cooling Standard kW 1.55 1.99
Heating Standard kW 1.60 2.04
For
combination
indoor units +
outdoor units
EER Nominal 3.23 3.02
COP Nominal 3.63 3.43
Energy
Labeling
Directive
Cooling A B
Heating A B
Annual energy consumption kWh 775 995
Indoor Units FTYN50FV1B FTYN60FV1B
Cooling
capacity
Standard kW 5.0 6.0
Heating
capacity
Standard kW 5.8 7.0
Nominal input Cooling Standard kW 1.55 1.99
Heating Standard kW 1.60 2.04
For
combination
indoor units +
outdoor units
EER Nominal 3.23 3.02
COP Nominal 3.63 3.43
Energy
Labeling
Directive
Cooling A B
Heating A B
Annual energy consumption kWh 775 995
2-2 TECHNICAL SPECIFICATIONS RYN50E3V1B RYN60E3V1B
Casing Colour Ivory White
Dimensions Unit Height mm 735 735
Width mm 825 825
Depth mm 300 300
Packing Height mm 797 797
Width mm 960 960
Depth mm 390 390
Weight Unit kg 48 48
Packed Unit kg 53 53
Heat
Exchanger
Dimensions Length mm 845 845
Nr of Rows 2 2
Fin Pitch mm 1.80 1.80
Nr of Stages 32 32
Tube type Hi-Xa(8)
Fin Type Waffle fin
Treatment Anti-corrosion treatment (PE)
Fan Type Propeller
Quantity 1 1
Air Flow Rate
(nominal at
230V)
Cooling m³/min 48.9 50.9
Heating m³/min 45.0 46.3
Motor Quantity 1 1
Model KFD-380-50-8A
Motor Speed
(nominal)
Cooling rpm 780 810
Heating rpm 720 740
Fan Motor Output W 53 53
