Daikin Super Multi NX FCQ50C8VEB

SiBE121021_C Outdoor Unit - 80/90 Class
Removal Procedure 411
11
Remove the front panel
(1).

Be sure to detach the front
panel (1) carefully so as not
to deform it.
6. Remove the rear panel.
1
Remove the screw on
the partition plate (2).
Step
Procedure Points
(R10385)
(R6396)
(R11209)
Rear panel
Partition plate (2)
