SiBE121021_C Function of Indoor Unit (RA Models)
Function and Control 93
Heating
Wall Mounted Type: FTXG and CTXG Series, FTXS Series 60/71 Class
Wall Mounted Type: FTXS and ATXS Series 20-50 Class
Floor Standing Type
Floor / Ceiling Suspended Dual Type
Duct Connected Type
Refer to “Temperature Control” on page 84 for detail.
OFF
ON
B
A
C
1.5˚C
2.0˚C
0.5˚C
Room thermistor temperature – target temperature
(R11894)
B
A
OFF
ON
C
1.5˚C
1.0˚C
Room thermistor temperature – target temperature
0˚C
(R12320)
B
A
OFF
ON
C
1.5˚C
0.5˚C
1.0˚C
Room thermistor temperature – target temperature
(R12392)
To Next Page
