RA Indoor Unit SiBE121021_C
190 Operation Manual
2.3 ATXS, FLK(X)S, FDK(X)S Series - ARC433B67, B68, B69,
B76
2.3.1 Manual Contents and Reference Page
★
1: The illustrations are for wall mounted type as representative.
★
2: The illustrations are for duct connected type as representative.
Model Series
Wall Mounted Type
Floor / Ceiling Suspended Dual
Type
Duct Connected Type
ATXS20-50G2V1B FLK(X)S25-60BAVMB
FDK(X)S25/35EAVMB
FDK(X)S50/60CVMB
Read Before Operation
Remote Controller 191 192 193
Operation
AUTO · DRY · COOL · HEAT · FAN
Operation
★
1
194 194 194
Adjusting the Airflow Direction 196 198 —
COMFORT AIRFLOW Operation 200 — —
INTELLIGENT EYE Operation 201 — —
POWERFUL Operation
★
1 203 203 203
OUTDOOR UNIT QUIET Operation
★
1 204 204 204
ECONO Operation 205 — —
HOME LEAVE Operation
★
2 — 206 206
TIMER Operation
★
1 208 208 208
Note for Multi System 210 210 210
Drawing No. 3P207037-2D 3P194444-5C 3P196326-9C
To Next Page
