RA Indoor Unit SiBE121021_C
162 Operation Manual
Indoor Unit
22˚C
25˚C
Model
COOLING
ONLY
HEAT
PUMP
Mode
COOL
AUTO
Temperature
setting
Airflow
rate
AUTO
AUTO
1. Titanium Apatite Photocatalytic
Air-Purifying Filter:
• These filters are attached to the inside of
the air filters.
2. Air outlet
3. Display
4. Front panel
5. Vertical blades (louvers)
• The louvers are inside of the air outlet.
6. Air inlet
7. Air filter
8. Horizontal blade (flap)
9. Operation lamp (green)
10. TIMER lamp (yellow)
11. Indoor Unit ON/OFF switch:
• Push this switch once to start operation.
Push once again to stop it.
• The operation mode refers to the following
table.
• This switch is useful when the remote
controller is missing.
12. Signal receiver:
• It receives signals from the remote
controller.
• When the unit receives a signal, you will
hear a short beep.
• Operation start ........ beep-beep
• Settings changed ..... beep
• Operation stop.......... beeeeep
13. Air outlet selection switch
14. Room temperature sensor:
•
It senses the air temperature around the unit.
To Next Page
