SA Indoor Unit - FFQ, FCQ, FDBQ, FBQ, FHQ Series SiBE121021_C
228 Operation Manual
English 9
1. Operation mode selector button
2. Fan speed control button
3. Menu/Enter button
• Used to indicate the main menu.
(See page 24 for the menu items.)
• Used to enter the setting item selected.
8. On/Off button
9. Operation lamp (Green)
10. Cancel button
11. LCD (with backlight)
• Press this button to select the operation
mode of your preference. (See page 14.)
* Available modes vary with the connecting
model.
• Press this button to select the fan speed of
your preference. (See page 15.)
4. Up button (Be sure to press the
part with the symbol )
5. Down button (Be sure to press
the part with the symbol )
6. Right button (Be sure to press
the part with the symbol )
7. Left button (Be sure to press
the part with the symbol )
* Available fan speed vary with
the connecting model.
• Used to lower the set temperature.
• The next items on the lower side will be
highlighted.
(The highlighted items will be scrolled
continuously when the button is kept
pressed.)
• Used to change the item selected.
• Used to raise the set temperature.
• The next items on the upper side will be
highlighted.
(The highlighted items will be scrolled
continuously when the button is kept
pressed.)
• Used to change the item selected.
• Used to highlight the next items on the
right-hand side.
• Each screen is scrolled in the right-hand
direction.
• Home leave settings are enabled with this
button kept pressed for at least four
seconds. (See page 19.)
• Used to highlight the next items on the
left-hand side.
• Each screen is scrolled in the left-hand
direction.
• Home leave settings are enabled with this
button kept pressed for at least four
seconds. (See page 19.)
• Press this button and system will start.
• Press this button again and system will
stop.
• This lamp lights up during operation.
• This lamp blinks if a error occurs.
• Used to return to the previous screen.
• The backlight will be light for approximately
30 seconds by pressing any operation
button. Operate buttons excluding the On/
Off button while the backlight is lit.
• If two remote controllers are used to control
a single indoor unit, the backlight of the
remote controller operated earlier than the
other one will be lit.
To Next Page
