SA Indoor Unit - FFQ, FCQ, FDBQ, FBQ, FHQ Series SiBE121021_C
242 Operation Manual
24 English
The main menu has the following items.
Setting and display items
Reference page
Set temp mode changeover
Select normal set temperature or limit control.
27
Airflow direction setting
Used to make airflow direction settings.
28
31
Ventilation
Ventilation rate
Used to set to “Low” “High”
32
Ventilation mode
33
Timer setting
Schedule timer
Up to 5 actions can be set for each day.
35
Off reminder timer
Used to set each operation period of the system.
42
44
Quick Reference of Main Menu Items
Description
• The airflow direction blade are automatically
operated up and down (left and right).
• The fixed airflow directions are set to five
positions.
Used to set the room to a conformable
temperature quickly (unless the system is
not in program dry or fan operation).
• The maximum quick cooling/heating
operation period is 30 minutes.
Used to set Automatic, Heat exchange, and
Bypass.
• Operation start time and stop time can be
set according to the day of the week.
Either one of the following operation modes
can be selected.
• Operation at set temperature: Normal
operation
• Operation within set temperature range
(between max. and min. temperatures):
Limit operation
• Convenient holiday settings and temporary
closure settings are possible.
Service Contact/Model
Information
Ventilation
operation
settings for total
heat exchanger
Quick Cooling/Heating On/Off
(SkyAir only)
Used to display the service contact and model
information.
• Possible to set in 10 minute units from 30 to
180 minutes.
* This function is not available to all models.
* Clock settings are necessary.
* The system goes into schedule timer operation
in the previous mode set for the system.
