Specifications 19
50 Hz, 220 - 230 - 240 V
Model FTXS50G2V1B FTXS20J2V1B
Rated Capacity 5.0 kW Class 2.0 kW Class
Front Panel Color White White
Airflow Rates
H
m³/min
(cfm)
10.2 (360) 9.4 (332)
M 8.6 (305) 7.4 (261)
L 7.0 (246) 5.5 (194)
SL 6.0 (212) 4.1 (145)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.12 - 0.12 - 0.11 0.09 - 0.08 - 0.08
Power Consumption (Rated) W 26 - 26 - 26 18 - 18 - 18
Power Factor (Rated) % 98.5 - 94.2 - 98.5 90.9 - 97.8 - 93.8
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 274 × 870 × 366 289 × 870 × 366
Weight (Mass) kg 10 9
Gross Weight (Gross Mass) kg 13 13
Operation
Sound
H / M / L / SL dB(A) 43 / 39 / 34 / 31 38 / 32 / 25 / 22
Sound Power dB(A) 59 54
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
9.5
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D059731 3D070569A
Model FTXS25J2V1B FTXS35J2V1B
Rated Capacity 2.5 kW Class 3.5 kW Class
Front Panel Color White White
Airflow Rates
H
m³/min
(cfm)
10.8 (381) 11.4 (403)
M 7.9 (279) 8.7 (307)
L 5.2 (184) 5.8 (205)
SL 3.7 (131) 4.4 (155)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.09 - 0.08 - 0.08 0.12 - 0.12 - 0.11
Power Consumption (Rated) W 18 - 18 - 18 26 - 26 - 26
Power Factor (Rated) % 90.9 - 97.8 - 93.8 98.5 - 94.2 - 98.5
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 289 × 870 × 366 289 × 870 × 366
Weight (Mass) kg 9 10
Gross Weight (Gross Mass) kg 13 14
Operation
Sound
H / M / L / SL dB(A) 41 / 33 / 25 / 22 45 / 37 / 29 / 23
Sound Power dB(A) 57 61
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D070570A 3D070571A
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
