Outdoor Unit - 50~75 Class SiBE121021_C
374 Removal Procedure
9
Remove the 4 screws
of the discharge grille.
10
11
Remove the 2 screws
of the stop valve cover.
Slide the stop valve
cover downward and
remove it.
îš„
When reassembling, make
sure to fit the 5 hooks.
Step
Procedure Points
Discharge grille
(R12902)
(R11206)
Stop valve cover
