Indoor Unit SiBE121021_C
52 Printed Circuit Board Connector Wiring Diagram
[A3P]: INTELLIGENT EYE Sensor PCB
[A2P]: Signal Receiver / Display PCB
S52 S51
S1W JA
H2P
H1P
3P254832-1
S36
3P255914-1
