SiBE121021_C Remote Controller
Printed Circuit Board Connector Wiring Diagram 79
PCB Detail [A3P]: Signal Receiver PCB
[A4P]: Display PCB (BRC7E530W/531W)
★
LED5 and LED6 do not function.
[A4P]: Display PCB (BRC7F532F/533F)
★
LED5 and LED6 do not function.
[A4P]: Display PCB (BRC7EA63W/66)
★
LED5 and LED6 do not function.
3P156326-2
X2A
SS2
SS1
X1A
LED4
X1A
BS1
3P086209-1
LED3 LED2 LED1
LED4
BS1
X1A
LED3 LED2 LED1
3P174795-1
BS1
X1A
LED3
LED4
LED2
LED1
3PA58761-1
