18 | P a g e
Chiller Outline Dimension and Load Distribution
6.2.1 Spring Isolator Position
• Single System (UAA105 – UAA220)
UAA-ST3M
Spring Isolator Distance (Round Hole 18.0mm)
Total Base Length
AA
AB
AC
AD
AE
105
500
2250
500
3250
125
500
3150
500
4150
150
[A]
500
2025
2025
500
5050
[B]
500
4050
500
5050
175
500
2475
2475
500
6000
204
500
2475
2475
500
6000
220
500
1950
1950
1950
500
6850
UAA-
ST3M
Spring Isolator Model (Round Hole 18.0mm)
Total
No. of
Isolator
A1
A2
A3
A4
B1
B2
B3
B4
105
C1-
2080i
-
-
C1-
2080i
C1-
2080i
-
-
C1-
2080i
4
125
C1-
2330i
-
-
C1-
2330i
C1-
2330i
-
-
C1-
2330i
4
150
C1-
2510i
C1-
2080i
-
C1-
2510i
C1-
2510i
-
-
C1-
2510i
5
175
C1-
2080i
C1-
2080i
-
C1-
2080i
C1-
2080i
C1-
2080i
-
C1-
2080i
6
204
C1-
2080i
C1-
2080i
-
C1-
2080i
C1-
2080i
C1-
2080i
-
C1-
2080i
6
220
C1-
2080i
C1-
2080i
C1-
2080i
C1-
2080i
C1-
2080i
C1-
2080i
C1-
2080i
C1-
2080i
6
• All values in mm
• Please take note that UAA150 has 3 isolators on A side and 2 isolators on B side.
