Daikin UAA-ST3M - Control Panel Layout

Page | 9
4.2 Control Panel Layout
Item
Function
Description
1
Q0 (Unit Switch)
OFF
Turn OFF the unit
ON
Turn ON the unit
2
Q1 (1#SYS SW)
OFF
Turn OFF System 1
ON
Turn ON System 1
3
Q2 (2#SYS SW)
OFF
Turn OFF System 2
ON
Turn ON System 2
4
CM1
Indicating working current for 1#SYS Compressor
5
CM2
Indicating working current for 2#SYS Compressor
