General Constructions SiE00-01
2 General Constructions
1. General Constructions
1.1 Explanation
VAM150FJVE
VAM250FJVE
VAM350FJVE
VAM500FJVE
VAM650FJVE
VAM800FJVE
VAM1000FJVE
1 Ceiling Hock 2 Duct Connection Flange
3 Exhaust Fan 4 Air Filter (Long Life Filter)
5 Damper 6 Switch Box
7 Maintenance Cover 8 Heat Exchange Elements
9 Name Plate 10 Air Supply Fan
11 Remote Controller (Option Parts) 12 Damper Motor
13 EA (Exhaust Air) [Exhaust Air to Outdoor] 14 OA (Outdoor Air) [Fresh Air from Outdoor]
15 Maintenance Space for The Air Filters, Heat
Exchange Elements and Switch Box
16 RA (Return Air) [Exhaust Air from Room]
17 SA (Supply Air) [Feed Air to Room]
