ENGLISH
PARTS NAMES
Indoor unit
1- Room temperature sensor.
2- Front panel.
3- Air inlet.
4- Air filter.
5- Air outlet.
6- Vertical air flow louver.
7- Horizontal air flow grille.
8- Display panel.
9- Infrared signal receiver.
10- Remote Controller.
11- Control panel.
Outdoor unit
12- Drain hose, refrigerant connecting pipe
and electric wiring.
13- Air inlet (side and rear).
14- Air outlet.
Display panel
The operating conditions are indicated below:
1 Operation Lamp
2 Automatic Lamp
3 Timer Lamp
4 Economic Lamp
5 Pre-defrost Lamp
(Cooling only type without).
6 Infrared signal receiver
10 cm or more
60 cm or more
100 cm or more
60 cm or more
Air outlet
4.5 cm or more
