INTRODUCTION
The DK-200/DK-210 functions as a squeeze keyer with the DASH/DOT memory.
The ratio of DASH/DOT and SPACE can be adjusted with the WEIGHT Control.
With the WEIGHT control feature, you can adjust for the best DASH/DOT and SPACE ratio for each
operating speed.
Two types of keying outputs are available: GRID BLOCK and DIRECT.
A side-tone oscillator built in.
LED speed indicator (Model DK-210 only).
The DK-200/DK-210 can be powered by a 9 Volt battery.
Three modes: Automatic, Semi-Automatic and Tune (continuous tone) can select by MODE switch.
SPECIFICATIONS
Speed 8 WPM ... 50 WPM
Side-tone oscillator frequency 500 ... 3000 Hz
Keying output circuitry GRID BLOCK: 100 V, 10 mA max.
DIRECT: +300 V, 100 mA max., –100 V, 10 mA
Power consumption 13.8 VDC (9 ... 15 V) approx. 100 mA / DK-200
200 mA / DK-210
or a 9 Volt battery can be installed inside the cabinet
Dimensions 150 mm W × 62 mm H × 150 mm D; 0,9 kg
LED Speed indicator DK-210 only
Other
RCA plug 2 pcs
Stereo phone plug 1 pc
DC plug with cord 1 pc
NOTE: The keyer can be operated by an AC adaptor (DC 12 V, 200 mA; maximum voltage of the
adaptor should not be exceeded DC 15 V when no load connecting).
PARALLEL CONNECTION OF TRANSCEIVERS
