ENERGISER DISPLAY Models MT5, MT15, 35 & BT12, 20
1. Overload red LED - flashes slowly (once per pulse) when the load exceeds an acceptable level. When
this occurs it is likely that the fence has a fault. Operating into an overload will NOT harm the MT60 / 100,
BT50 / 80. This LED also flashes quickly to indicate a low battery or energiser error.
2.
Energiser OK green LED - Flashes with each pulse to show the unit is operating correctly.
.3
KiloVolts display – Shows the voltage on the output terminals of the energiser. The higher the voltage
the more effective the fence will be.
.4
Load Factor display – from 0 to 10, 10 being a dead short circuit, 0 being no fence load at all. Indicates
the fence load at the energiser. Useful for a quick check of fence health.
ERROR CODES
Battery powered energisers may see the red Overload LED flash twice (2) in succession, or for models
featuring digital display a reading of
Lo b, this means low battery voltage. (Early models will switch
themselves off to conserve the battery on re-applying the correct voltage the energiser will start up). At this
warning
indication your battery needs to be re-charged to prevent permanent battery damage and loss of fence
voltage.
Should the red overload LED flash 3 or more times in succession, or for models featuring digital display
a reading
Er 03, 04 or 05 your energiser will require service, please return to the point of purchase for
professional care.
ENERGISER DISPLAY MT60, 100 & BT50, 80
PAGE 4 – DAKEN Users Manual
MT35 Energiser showing LED display
1. Overload red LED - flashes slowly (once per pulse) when the load exceeds an acceptable level. When
this happens it is likely that the fence has a fault. Operating into an overload will NOT harm the MT15/35,
BT10 / 20. This LED also flashes quickly to indicate an energiser error.
2.
Energiser OK green LED - Flashes with each pulse to show the unit is operating correctly.
BT80 Energiser showing LED display
