3-10 Specifications
Model Number of
Sections
Dimensions
(Height, Width,
Depth)
Weight
Uncrated
(Crated)
Digit Size
Digit Color
Maximum
Wattage
Power Amps
per Line
(Single
Phase)
Driver
Number
and
Address
FB-1530
w/TMNC
2 Total
Top and
Bottom
H8’-0”, W25’-0”, D6”
(2438 mm, 7620
mm, 152 mm)
H4’-0”, W25’-0”, D6”
(1219 mm, 7620
mm, 152 mm)
700 lb
(318 kg)
1330 lb
(603 kg)
 Clock 30”
(457 mm)
 All Others
24” (610
mm)
 Indicators 8”
(203 mm)
-11: red
-21: amber
600 W
(w/red
TNMC)
600 W
(w/amber
TNMC)
120 V AC 5.0 A
5.0 A
A1 12
FB-1624 2 Total
Top and
Bottom
H8’-0”, W18’-0”, D6”
(2438 mm, 5486
mm, 152 mm)
H4’-0”, W18’-0”, D6”
(1219 mm, 5486
mm, 152 mm)
440 lb
(200 kg)
836 lb
(379 kg)
 Indicators 8”
(203 mm)
 All others
24” (610
mm)
-11: red
-21: amber
600 W 120 V AC 5.0 A A1 15
A2 16
FB-1630 2 Total
Top and
Bottom
H8’-0”, W25’-0”, D6”
(2438 mm, 7620
mm, 152 mm)
H4’-0”, W25’-0”, D6”
(1219 mm, 7620
mm, 152 mm)
600 lb
(272 kg)
1140 lb
(517 kg)
 Clock 30”
(762 mm)
 TOL 18”
(457 mm)
 Indicators 8”
(203 mm)
 All Others
24” (610
mm)
-11: red
-21: amber
600 W 120 V AC 5.0 A A1 15
A2 16
