Signal Connection
Reference Drawings:
Connection Diagram: BB-2140 & BB-2141 ....................................................... DWG-184789
Connection Diagram; BB-2150 & BB-2151 ..................................................... DWG-1060264
Signal installation requires routing control cable from the control console to a signal
junction box (J-box) near the display, routing cable from the J-box to the control
enclosure, and routing the appropriate cables from the system components to the
control enclosure. At a minimum, use a paired, 22 AWG shielded cable (Daktronics part
# W-1077).
1� Connect the cable to a 1/4" J-box at the control console end.
2� Route the cable in conduit from the J-box on the control console end to a J-box near
the display.
3� Install the 1/4" phone plug (part # 0L-40683) to the display end of the cable. Be sure
to connect the cable shielding only in the J-box on this end. DO NOT connect cable
shielding at the J-box near the control console.
4� Insert the plug into the J31 SIGNAL IN jack on the front of the control enclosure.
5� Connect the shot clock(s), remote horn enclosure, and any optional light strip kits to
the appropriate jacks on the control enclosure as shown in DWG-184789 and DWG-
1060264.
6� Connect a signal cable from the J-box to the J1, J2, or J3 jack on the back of the All
Sport 5000 console.
Also connect the Shot Clock Start/Stop Switch (Daktronics part # 0A-1196-0031) to the
J7 jack on the All Sport 5000.
Radio Control
Radio control is an option for Daktronics shot clocks. The system provides scoreboard
control via a 2.4 GHz, extra-high frequency FM signal.
The radio transmitter and receiver are not standard equipment. This setup requires a
control console equipped with radio output as well as a radio receiver plugged into
the J7 jack in the control enclosure and mounted internally to the front panel of the
enclosure.
Note: A 5-pin to 6-pin adaptor (Daktronics part # W-2913) is required to connect newer
radio units to the shot clock driver.
For additional information about this option, contact a Daktronics representative. For
complete instructions on setting up radio control, refer to the Gen VI Radio Installation
Manual (DD2362277), available online at www.daktronics.com/manuals.
Light Strips
For installations that use LED backstop light strips, refer to the LED End-of-Period Basketball
Lighting Display Manual (ED-13652), or the BB-2135 Backboard LED Light Strips Display
Manual (ED-14187), both available online at www.daktronics.com/manuals.
