Dalbach UBH60-01 - Extractor Hood Installation Clearances; Required Minimum Clearances

EN
Page | 34
Insert the selection element (4) for air
extraction mode.
Remove the selection element (4) for
recirculating air mode.
Appliance
Minimum clearances
The following minimum clearances from the upper edge of the hob to the lower
edge of the extractor hood must be observed when installing the extractor hood:
• so that the mains plug is accessible at all times
• Do not connect to mains power supply via multiple sockets or extension
leads.
• and do not operate outdoors.
• in accordance with the prescribed minimum clearances.
Clearance
(a)
Electric
stoves
650 mm
Gas stoves
700 mm
max.
750 mm
