EPIKORE 11, 9, and 7:
We recommend unpacking DALI EPIKORE loudspeakers
close to their intended final position.
EPIKORE loudspeakers are heavy so unpacking should be
undertaken by two people working together.
3. Unpacking DALI EPIKORE 11, 9, and 7
Slowly flip the carton 180°.
A
With the carton now lying on its front it can be lied away, leaving the EPIKORE held in its inner packaging.
B
If you need assistance
with the installation,
please contact your
local DALI dealer.
Remove top part of transport box.
A
Li the EPIKORE grille out of the carton and place it out of the way.
B
180°
Remove the accessory box.
A
Remove the two packing end caps
B
to leave the EPIKORE supported by the remaining centre packing blocks.
Open the cabinet protection cloth in the boom of the loudspeaker
C
.
C
5DALI EPIKORE ManualDALI EPIKORE Manual4
