Dali EPIKORE 3 - Page 5

B
A
A
5mm
B
9
8
A
2
3
Screw a lock nut thumbscrew
A
by hand to the top of each Spike.
Remove the EPIKORE tweeter dome protector.
B
Carefully tilt the EPIKORE to the side with the
magnetic spike protectors aached, so that the
floor protection pads can be removed.
If the magnetic spike protectors are to be used,
apply the two remaining spike protectors under
the spikes on one side while the loudspeaker is
tilted. If the spike protectors are not to be used,
remove the previously applied spike protectors
by carefully tilting the speaker to the other side.
Adjust the spikes
A
so that the loudspeaker is
stable using the 5mm Allen key.
B
Do not overtighten.
EPIKORE 3:
We recommend unpacking DALI EPIKORE 3 loudspeakers
close to their intended final position.
4. Unpacking DALI EPIKORE 3
1
Open transport box.
Li the EPIKORE grille out of the
carton and place it out of the way.
A
Slowly flip the carton 180°.
With the carton now lying on its front it can be lied away,
leaving the EPIKORE 3 held in its inner packaging.
A
Remove the accessory box.
B
Carefully take the DALI EPIKORE 3 loudspeaker out of
the inner packaging. Place it on its final position.
Remove the protection cloth.
C
C
A
Remove the EPIKORE tweeter dome
protector.
A
A
For positioning on stand
- see next page.
A
B
9DALI EPIKORE ManualDALI EPIKORE Manual8
