24
FAZON SAT
Frequency Range +/-3dB [Hz] 86 - 25,000
Sensitivity (2.83V/1m)[dB] 86
Nominal Impedance [ohm] 6
Maximum SPL [dB] 104
Crossover Frequency [Hz] 1,800
Enclosure Type Closed Box
Recommended Amplifier Power [Watt] 20 – 120
High Frequency Driver [mm] 1 x 28 soft dome
Low Frequency Driver [inches] 1 x 4½
Terminals Integrated in Twist ‘n’ Tilt bracket
Dimensions (H x W x D) [inch] (Wall mounted) 10.2 x 5.5 x 5.5
Dimensions (H x W x D) [cm] (Wall mounted) 26.0 x 14.0 x 14.0
Dimensions (H x W x D) [inch] (Stand mounted) 11.4 x 5.8 x 6.8
Dimensions (H x W x D) [cm] (Stand mounted) 29.0 x 14.6 x 17.2
Weight [kg/lbs] 2.35/5.18
Finish Black or White High Gloss Lacquer
Accessories Table Stand, Bracket,
2 mm Allen key, 2.5 mm Allen key,
3 mm Allen key, Mounting template,
Manual
TABLE 2 - FAZON SAT TECHNICAL SPECIFICATIONS
All technical specifications are subject to change without notice.
