dallara F-317 - WHEEL;ARB RATIO; STD (A1) Rear ARB Ratios

F 317
Owners Manual / Manual de Usuario
Euroformula Open Technical Comision
Comisión Técnica del Euroformula Open
21/78
Version 1801 of April 2018
Versión 1801 de Abril de 2018
Static Motion Ratios / Relación
estática de movimiento
ARB Type / Tipo Barra anti-balanceo
Droplink Position /
Posición extremo
Spring /
Muelle
3rd
ARB /
Barra
[Rocker /
balancín]
[ARB] /
[Barra]
STD (A1)
T Φ14 Double T-bar (soft arb)
T Φ17 Non-Adjustable Blade T-bar
T Φ25 Non-Adjustable Blade T-bar
/
T Φ14 Doble Barra T (Blando)
T Φ17 Bieleta no ajustable T
T Φ25 Bieleta no ajustable T
Narrow /
Estrecho
1
1,289
1,326
1,549
2
1,289
1,286
1,503
3
1,289
1,249
1,459
4
1,289
1,213
1,418
5
1,289
1,180
1,380
6
1,289
1,148
1,343
7
1,289
1,118
1,308
T Φ14 Double T-bar (soft arb)
T Φ17 Non-Adjustable Blade T-bar
T Φ25 Non-Adjustable Blade T-bar
/
T Φ14 Doble Barra T (Blando)
T Φ17 Bieleta no ajustable T
T Φ25 Bieleta no ajustable T
Wide /
Ancho
1
1,289
1,766
2,056
2
1,289
1,699
1,979
3
1,289
1,637
1,907
4
1,289
1,579
1,841
5
1,289
1,525
1,779
6
1,289
1,475
1,721
7
1,289
1,428
1,666
RATIO = WHEEL/ARB
[WHEEL vertical travel / ARB drop link travel]
RELACIÓN = RUEDA / BARRA
[Despl. Vert. rueda / Mov. Extremo bieleta]
