AERODYNAMIC INFORMATION 24
• Front wing main-plane and rear lower wing are set relative to the chassis reference
plane.
• The optimum setting for the front main-plane is -1° (minus 1°). Any chassis rake angle
will alter this setting.
• Front flap inclination is intended to be the angle, relative to the chassis reference plane,
measured on top of the flap front and inside the Gurney ‘corner’.
• Rear top wing assembly inclination is intended to be the angle, relative to the chassis
reference plane, measured between the front of the flap, on top and the rearmost
trailing edge. Any chassis rake will alter this setting.
• Front and rear ride height settings are fundamental to the aerodynamic balance and
ultimate performance of the car. Pay attention to the changes between static setting and
the dynamic values on the track.
MINIMUM MAXIMUM
HOLE INCIDENCE HOLE INCIDENCE
FRONT MF FLAP A1 7° G4 34°
FRONT SF FLAP A1 10° G4 37°
REAR TOP MDF WING A1 2° D4 23°
REAR TOP HDF WING A1 2° D4 23°
REAR LOWER -1° 10°
REAR LOWER 7° 18°
BALANCE
HOW TO BALANCE +1° FRONT FLAP BY CHANGING THE REAR WING, REAR
RIDE HEIGHT OR FRONT RIDE HEIGHT?
Front
flap type
Rear top: MDF
Front
flap type
Rear top: HDF
0.9 holes
RR top
1.2 holes
RR top
2.7mm lower
RR height
2.2mm lower
RR height
MF
1.7mm higher
FR height
SF
4.0mm higher
FR height
MF: MEDIUM FLAP; SF: STANDARD FLAP
