Danby DMW769W - Door Parts List; Control Parts List

7-3
7-3 Door Parts List
7-4 Control Parts List
7-5 Body Latch Parts List
Ref. No. Parts No. Description/Specification Q'ty Remarks
B 1 DE66-40001C LATCH-BODY;PP,NTR,3RD-W 1
B 2 3405-000178 SWITCH-MICRO;250V,15A,200gf,SPST-NO 3
B 3 3405-000175 SWITCH-MICRO;250V,15A,200gf,SPST-NO 1
B 4 DE66-90114A LEVER-S/W;PP,-,-,-,-,3RD-W 1
Exploded Views and Parts List
Ref. No. Parts No. Description/Specification Q'ty Remarks
D 1 DE64-00004A DOOR-A;ABS,-,DANBY07 1 DMW769W/-1
D 1 DE64-00004B DOOR-A;ABS(HR0370D),BLK,DMW769BL 1 DMW769BL/-1
D 2 DE64-40006A DOOR-KEY;POM(TC3005),T2.0,12GR,BLK,CE94 1
D 3 DE61-70033A SPRING-KEY;ES,HSWR10,PI0.6,D6.0,L22.3,BLU 1
D 4 DE67-20186A SCREEN-DOOR;SAN,T2.2,W354,L224,SMOG,3RD-0.7CU.FT 1
D 5 DE92-50133C ASSY DOOR-E;MW4593G,-,BLK,3RD-0.7 1
D 6 DE64-40008B DOOR-C;PP,T1.5,BLK,CE745G 1
D 7 DE01-00112A FILM-DOOR;PET,T0.15,W150,L268,NTR,3RD-W 1
Ref. No. Parts No. Description/Specification Q'ty Remarks
C 1 DE66-00002A BUTTON-PUSH;ABS 1
C 2 DE61-70076A SPRING-BUTTON;HSWR,PI0.6 1
C 3 DE34-00019A SWITCH-MEMBRANE;PET ,DMW769W,120V60HZ,DANBY 1 DMW769W/-1
C 3 DE34-00019B SWITCH-MEMBRANE;PET ,DMW769BL,120V60HZ 1 DMW769BL/-1
C 4 DE72-00005A CONTROL-PANEL;DANBY07,T2,-,-,-,P/WHT,- 1 DMW769W/-1
C 4 DE72-00005B CONTROL-PANEL;ABS(HR0370D),DMW769BL,BLK 1 DMW769BL/-1
C 5 DE97-00048A ASSY PCB-MAIN;RA-W3LCD2-03,DMW109W 1
C 6 DE94-00133A ASSY CONTROL-PANEL;120V60HZ,DMW769W,P/WHT,DANBY 1 DMW769W/-1
C 6 DE94-00133B ASSY CONTROL-PANEL;120V60HZ,DMW769BL,BLK,DANBY 1 DMW769BL/-1
C 7 DE71-00022A COVER-LCD;ABS,-,-,-,BLK,3RD DANBY 1
