Danby DMW769W - Standard Parts List

7-4
7-6 Standard Parts List
Exploded Views and Parts List
Parts No. Description / Specification Q'ty Remarks
DE60-10080A SCREW-WASHER;M5,L12,2S 4 HVT
DE60-10080A SCREW-WASHER;M5,L12,2S 4 MGT
DE60-10082H SCREW-A;2S-4X12,TOOTHED 4 B-PLATE
DE60-10082H SCREW-A;2S-4X12,TOOTHED 2 BD-LAT
DE60-10082H SCREW-A;2S-4X12,TOOTHED 1 CON-BOX
DE60-10082H SCREW-A;2S-4X12,TOOTHED 1 CV-AIR
DE60-10082H SCREW-A;2S-4X12,TOOTHED 2 OUT-PA
DE60-10082H SCREW-A;2S-4X12,TOOTHED 1 P/CORD
DE60-10082H SCREW-A;2S-4X12,TOOTHED 1 PCB-GND
DE60-10098A SCREW-ASSY TAP TITE;PH,TC,M4X8,SWRCH18A,ZPC2,GLD,W 2 G-MOTOR
DE60-10098A SCREW-ASSY TAP TITE;PH,TC,M4X8,SWRCH18A,ZPC2,GLD,W 2 TCO
DE60-10122A SCREW-TAP TH;TAP,TH,2-4X8,FE,FN 1 OUT-PA
DE60-10195A SCREW-STAR POLE;TH,*,2,4,12,SWCH18A,ZNC 2 -
DE60-30016A NUT-FLANGE;M4,MSWR10 2 F-MOTOR
DE60-10098A SCREW-ASSY TAP TITE;PH,TC,M4X8,SWRCH18A,ZPC2,GLD,W 1 -
DE60-10012A SCREW-TAP TITE;TH,+,3,M4,L10,SWR10,ZPC2,TOOTH 1 -
DE60-10088A SCREW-TAP PHPH,M3,L8,FEFZY,PLAIN 2 PCB
