10
INSTALLATION INSTRUCTIONS
INSTALLING THE WINDOW KIT
The instructions below can be used for a hung window application (shown on the left) or an optional
sliding window application (shown on the right).
1. Cut adhesive foam seals A and B to the correct lengths and attach them to the window frame as shown.
B
A
B
A
2. Insert the window slider kit into the window opening and close the window the secure it in place.
A
B
A
B
3. Cut the non-adhesive foam seal C to match the width or height of the window and insert it between the
panes of glass as shown to prevent outside air from entering the window.
C
C
