12
OPERATING INSTRUCTIONS
FEATURES
1. Control panel
2. Handle (both sides)
3. Casters
4. Upper air fi lter
5. Upper air intake
6. Exhaust hose
7. Continuous drain
8. Power cord storage band
9. Bottom tray drain
1
2
3
4
5
6
7
8
9
LOCATION
Place the air conditioner on a smooth, level fl oor
that is strong enough to support it and all included
accessories. Make sure it is level to minimize noise
and vibration.
The air conditioner must be installed near a
grounded receptacle and the overfl ow drain outlet
on the rear must be accessible.
Do not cover air inlets or outlets or the remote
control receiver on the control panel.
The air conditioner requires 25 cm (10 inches)
of space on the sides and back for proper air
circulation. The louver blade should be 50 cm (20
inches) away from obstacles.
