Fahrzeug-/Funktionsdecoder ab Firmware-Version 1.11
29
Locomotive/Vehicle function decoder from firmware version 3.12
DH22B
PluX22 interface
1 2
3 4
5 6
7 8
9 10
11 12
13 14
15 16
17 18
19 20
21 22
GPIO
ZCLK
GND
LV
VS
Index
LR
--
--
AUX4
AUX6
AUX3
ZDAT
ZVS
M1
M2
G1
G2
AUX1
AUX2
AUX5
AUX7
M1, M2 Motor connection 1, 2
G1, G2
T
rack connection 1, 2
LV, LR Front light, rear light (each 150 mA)
AUX1, AUX2 Additional function 1, 2 (each 300 mA)
AUX3 ... AUX7
Additional function 3 ... 7 (each 1,0 A)
VS
Supply voltage
ZVS
SUSI supply voltage
ZCLK
SUSI clock
ZDAT SUSI data
GND Ground (0 V)
GPIO General input / output (max. +5 V / max. 3 mA)
or AUX8 unamplified *)
*)
Unamplified function outputs: See supplement 3.
If necessary: Connect blue wire (common return conductor) to VS.
You can connect a buffer capacitor to ZVS (+) and GND (-).
