CONTENTS
• Fast Operation: Superior heating system quickly brings
the platen to uniform temperature ensuring 100%
bonding.
• Extended Temperature Range: Thermostat control
adjusts from 100º F to 300º F (38 º –150º C) to cover a
wide range of operating temperatures.
•
Programmed Heating Cycles:
T
emperature and time may
be set by stored programs in control unit.
•
T
emperature Readout:
Platen temperatur
e is indicated
on LED display on top of unit.
• Cycle Time Readout: Remaining time in the cycle is
displayed.
• Oversize Capacity: Design allows processing of materials
larger than the press platen by sliding the work side-to-
side or out the front or back of the press.
• Extra-Wide Opening: Opens a full 9” (23cm) for 550
and 10” (25cm) for 250 to provide easy access to
platen surface.
• Easy Pressure Adjustment: Pressure adjusts and locks
in seconds to accept materials up to 1" (25mm) thick.
• Non-Stick Surface: Platen surface is specially coated to
help keep adhesives fr
om sticking.
• Free-Floating Platen: Seats evenly on the work without
shifting to pr
ovide uniform pressure acr
oss the entir
e
sur
face.
• Rugged Construction: Steel cantilevers increase
durability and allow maximum pr
essur
e on work
within the pr
ess. Metal top and base constr
uction
adds ruggedness.
PRESS FEATURES AND SPECIFICATIONS
2
Press Features and Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
I
mportant Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Identification of Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation and Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Program Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Procedures For Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Processing Oversize Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Pressure Adjustment Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Periodic Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
