VLT
®
5000 SyncPos option
MG.10.J4.02 – VLT is a registered Danfoss trade mark
152
Parameter Reference
69 SYNCMWINS
The Marker Window Slave SYNCMWINS shows
how large the permitted tolerance for the occur-
rence of the markers is.
With the works setting „0“ the window is not moni-
tored, which means that it is always synchronized
to the next marker even if this has a considerably
larger interval.
At every other setting only those markers are ac-
cepted which are within the window. If there is no
marker within the tolerance window the correspon-
ding flag (SYNCSTAT) is set and no marker correc-
tion takes place. The corresponding other marker
is also ignored and only corrected the next time –
i.e. no catching up to the next marker.
When SYNCM is started the monitoring only begins
when the first marker has been found.
Content
Tolerance window for slave marker monitoring
Parameter Group
AXS
Unit
qc
Value range
0 … MLONG or. max. Marker interval
SYNCMPULSS (59) 0
0 = The window is not monitored.
1 MLONG = Only one marker is accepted
within the window. If no marker
is within the tolerance window,
the corresponding flag
(SYNCSTAT) is set and no
marker correction carried out.
This flag can be reset with an
interrupt (ON STATBIT).
70 ESCCOND
With ESCCOND you can determine how the VLT
will react to a program termination using ESC.
Content
Condition on program termination
Parameter Group
Axis Parameters Inputs/Outputs AXI
Value range
0 … 2 0
0 = The motor is stopped with maximum
deceleration, the brake is activated (if
defined), the master simulation is stopped.
The outputs remain in the current status.
1 = As 0, but all outputs including the VLT
outputs 11, 14, 42 and 45 are set at „0“.
Exception: The brake output – if defined – is
always activated.
2 = As „0“, but all outputs including the VLT
outputs 11, 14, 42 and 45 are set at „1“;
Exception: The brake output – if defined – is
always activated.
