Danfoss DHP-AQ Maxi - Symbols on Decals

Appendix UK – 5
2.1.2 Manufacturer label: DHP-AQ
P. O. Box 950 SE-671 29 Arvika
Sweden
DHP-AQ CONTROL MAXI 6-13 SP
Heat Pump
Source of heat Max Mpa 0
System of heat Max Mpa 0
Source of heat Min/Max ˚C
Refrigerant Type *
Operation Pressure Min/Max MPa --
Refrigerant Kg
Connection
Electric connection V 230 1N~50Hz
Power input Total kW 3.1/6.1/9.1
Power input Heat pump kW
Power input Auxiliary Heater kW 3/6/9
Pressure Vessel
Volume Sec/Prim l 180/7.5
Design Pressure Sec/Prim MPa 1.0 / 0.3
Test Pressure Sec/Prim MPa 1.43 / 0.43
Design Temp ˚C 100
Rating condition EN 14511
B0W35 A2/W35 A7/W35
(see technical documentation)
Heating capacity kW --
Coefficient of Performance --
* This product contains fluorinated greenhouse
gases covered by the Kyoto Protocol
--
Serial No 086U0283xxxxxxxx
086L0283xxxxx
Model CU-*104-303 YY-WW 11-27
IP
x 2
