Caution Check installed fuses before making any settings.
Power
steps
Heating power in kW Control panel (single phase 1-N) fuse size
(A)
Control panel (three phase 3-N) fuse size (A)
1 3, immersion heater only 16 10
2 6, immersion heater only 30 16
3 9, immersion heater only 40 16
4 12, immersion heater only — 20
5 15, immersion heater only — 25
+4 12, immersion heater + com-
pressor
— 25
+5 15, immersion heater + com-
pressor
— 25
230V 1-N Electric auxiliary heater
The following settings are made in the Service Menu. If not already in the Service Menu, enter the Service Menu by pressing and holding
left (<) arrow for at least 5 seconds. Use + or – to move up and down in the menu.
Electric auxiliary heater for 230V, 1-N. Step 3 is highest setting
Setting of electric auxiliary heater for 230V, 1-N. Max step 3 in the SERVICE menu:
!
SERVICE
!
AUX. HEATER.
!
MAX STEP
!
Select max step
400V 3-N Electric auxiliary heater
The following settings are made in the Service Menu. If not already in the Service Menu, enter the Service Menu by pressing and holding
left (<) arrow for at least 5 seconds. Use + or – to move up and down in the menu.
Electric auxiliary heater for 400V, 3-N. Step 5 is highest setting
5 is highest setting
Setting of electric auxiliary heater for 400V, 3-N. Max step 5 in the SERVICE menu:
!
SERVICE
!
AUX. HEATER.
!
MAX STEP
!
Select max step
Commissioning
VIGFH102 Danfoss Heating Solutions
12
