3.2.4 Sub-menu TEMPERATURE
In the TEMPERATURE menu you are able to view the
various temperatures that the installation has had. All
temperatures are stored 100 minutes (factory setting)
back in time so that they can also be displayed in the
form of graphs.
Menu text Description Adjusted by:
OUTDOOR Outdoor temperature
ROOM If ROOM shows 20°C the heat curve is
unaffected. If ROOM shows higher or
lower, this indicates that the heat curve
has been adjusted up or down to change
the indoor temperature.
By the customer,
if necessary.
SUPPLY PIPE Indicates the measured supply tempera-
ture of the heating system. (The desired
value is shown between brackets.)
Not adjustable
(The computer calcu-
lates the temperature
required to maintain the
indoor temperature.)
RETURN PIPE Indicates the measured return tem-
perature of the heating system. (The
highest permitted temperature is shown
between brackets.)
Authorized installer.
Adjusted for each instal-
lation.
HOT WATER Indicates measured hot water tem-
perature. (The temperature at which
hot water production starts is shown
between brackets.)
Not adjustable
INTEGRAL Heat production is controlled by a calcu-
lated demand that is automatically cal-
culated when the installation is in opera-
tion. The integral is the heat system’s
energy balance.
Not adjustable
BRINE OUT The temperature of the brine when it
returns to the heat source.
Not adjustable
BRINE IN The temperature of the brine from the
heat source.
Not adjustable
TEMPERATURE
OUTDOOR -20°C
ROOM 20°C
SUPPLY PIPE 41(70)°C
RETURN PIPE 38(48)°C
HOT WATER 55(44)°C
INTEGRAL -660
BRINE OUT -7°C
