Danfoss DHP-L Opti

4.8 Outdoor unit DHP-A, DHP-AL, DHP-A Opti, DHP-AL Opti
6
7 8
1
2
3
4
5
Figure 10. Outdoor unit and connections
Symbol explanation
1 Outdoor unit 5 Cover
2 Cover 6 Connection, brine in to outdoor unit
3 Front cover 7 Connection, brine out from outdoor unit
4 Stand 8 Connection, drain drip tray
Service instructions VMGFC302 – 17
