User Guide | Superheat controller, EKC 315A
© Danfoss | DCS (ADAP-KOOL®) | 2015-03
DKRCI.PS.RP0.D2.02 | 520H7653 | 4
Ref. Di.
Function Para-
meter
Parameter by operation via
data communication
Normal display
Normally the superheat is shown (but the valve’s opening degree or air temperature
may also be selected. See o17).
SH / OD% / S3 temp
Reference
Se point
Regulation is performed based on the set value provided that there is no external
contribution (o10).
(Push both buttons simultaneously to set the setpoint).
- TempSetpoint.
Dierential
When the temperature is higher than the reference plus the set dierential, the sole-
noid valve’s relay will be activated. It will become deactivated when the temperature
drops below the set reference.
r01 Dierential
Unit
Here you select whether the controller is to indicate the temperature values in °C or
in °F. If indication in °F is selected, other temperature settings will also change over to
Fahrenheit, either as absolute values or as delta values
The combination of temperature unit and pressure unit is depicted to the right.
r05 Units
0: °C + bar
1: °F + psig
(in AKM only °C + bar – is displayed
– whatever the setting).
External contribution to the reference
This setting determines how large a contribution is to be added to the set setpoint
when the input signal is max. (20 mA). See o10.
r06 ExtRefOset
Correction of signal from S2
(Compensation possibility through long sensor cable).
r09 Adjust S2
Correction of signal from S3
(Compensation possibility through long sensor cable).
r10 Adjust S3
Start/stop of refrigeration
With this setting refrigeration can be started and stopped. Start/stop of refrigeration
can also be accomplished with the external switch function. See also appendix 1.
r12 Main Switch
Dene thermostat function
0: No thermostat function. Only the superheat is regulated
1: Thermostat function as well as regulation of superheat.
r14 Therm. Mode
Alarm
The controller can give alarm in dierent situations. When there is an alarm all the
light-emitting diodes (LED) will ash on the controller front panel, and the alarm relay
will cut in.
Alarm for upper deviation
The alarm for too high S3 temperature is set here. The value is set in Kelvin. The alarm
becomes active when the S3 temperature exceeds the actual reference plus A01. (The
actual reference can be seen in u28).
A01 Hgh.TempAlrm
Alarm for lower deviation
The alarm for too low S3 temperature is set here. The value is set in Kelvin. The alarm
becomes active when the S3 temperature drops below the actual reference minus
A02.
A02 Low.TempAlrm
Alarm delay
If one of the two limit values is exceeded, a timer function will commence. The alarm
will not become active until the set time delay has been passed. The time delay is set
in minutes.
A03 TempAlrmDel
With data communication the impor-
tance of the individual alarms can be
dened. Setting is carried out in the
“Alarm destinations” menu.
Survey of functions
