Danfoss FP715 Si User Manual

14
Table B cont...
DANFOSS RANDALL
FP715, CP715
(PUMPED)
MAINS
DHW
OFF
HTG
OFF
D
H
O
NL12
SMITHS IND. CENTROLLER 1000 N L - -
SMITHS IND. CENTROLLER 60 1 2 - -
SMITHS IND. CENTROLLER 10 N L - -
SMITHS IND. CENTROLLER 70 1 2 - -
SMITHS IND. CENTROLLER 1000 N L 1 2
SWITCHMASTER 320 & 350 N 4,L - -
SWITCHMASTER 400 N L - 4
SWITCHMASTER 600 N L - -
SWITCHMASTER 900 & 9000 N L 4 2
VENNER VENTROL N,A,M L,L,1 - -
VENNER VENOTROL 80 (AIR STAT)
N,1,
3,4
L--
VENNER VENOTROL 80 (AIR STAT
LINKED)
N,1
3,4
L--
VENNER CHC/W2 (WITH STAT) N,2,4 L - -
VENNER CHC/W2 (AIR STAT LINKED) N,2,4 L - -
VENNER VENOTROL 80P (WITH AIR
STAT)
N,1,3 L - 4
VENNER VENETROL 80P (AIR STAT
LINKED)
N,1,3 L - 4
Wiring Conversions

Danfoss FP715 Si Specifications

General

Battery Backup	Yes
Display	LCD
Operating Mode	Heating
Number of Channels	1
Switching Current	3A
Protection Class	IP30
Type	Programmer
Program	7-day, 5/2-day, or 24-hour
Switch Rating	3 A (resistive)
Temperature Range	5 to 30°C
Power Supply	230V AC
Output Type	Relay
Control Algorithm	On/Off
Operating Temperature	0 to 40°C
