ENGLISH
location not possible
*) ICF 15 - M1 and M2 modules are xed (stop valve and lter, respectively)
*) Not in combination with ICFO
ICF with six modules
Function Module Type Can be installed in these locations
ICFS/ICFS SS
Stop valve module M1 M2 M3 M4 M5 M6
ICFR/ICFR SS Manual regulating valve module M1 M2 M3 M4 M5 M6
ICFF/ICFF SS Filter (strainer) module M2 M4 M6
ICFE/ICFE SS Solenoid valve module M3
ICFC/ICFC SS Check valve module M4 M6
ICFN / ICFN SS Stop/check valve module M4 M6
ICM/ICM SS Motor valve module M1 M3 M5
ICFB/ICFB SS Blank top cover M1 M2 M3 M4 M5 M6
ICFA/ICFA SS Electronic expansion valve module (not for ICF 25) M1 M3 M5
ICFE 20H/ICFE SS 20H Solenoid valve module (not for ICF 25) M1 M3 M5
ICFO/ICFO SS Manual opening module (not for ICF 25) M4
ICFW/ICFW SS Welding module M1 M2 M3 M4 M5 M6
ICFD Defrost module M2 M4 M6
ICFG Pilot-operated servo module M3
Module locations are indicated by M1, M2, M3, M4, M5 and M6. With respect to refrigerant ow, M1 is closest to inlet.
ICF with four modules
Function Module Type Can be installed in these locations
ICFS/ICFS SS
Stop valve module M1 M2 M3 M4
ICFR/ICFR SS Manual regulating valve module M1 M2 M3 M4
ICFF/ICFF SS Filter (strainer) module M2 M4
ICFE/ICFE SS Solenoid valve module M3
ICFC/ICFC SS Check valve module M4
ICFN / ICFN SS Stop/check valve module M4
ICM/ICM SS Motor valve module M1 M3
ICFB/ICFB SS Blank top cover M1 M2 M3 M4
ICFA/ICFA SS Electronic expansion valve module (not for ICF 25) M1 M3
ICFE 20H/ICFE SS 20H Solenoid valve module (not for ICF 25) M1 M3
ICFO/ICFO SS Manual opening module (not for ICF 25) M4
ICFW/ICFW SS Welding module M1 M2 M3 M4
ICFD Defrost module M2 M4
ICFG
Pilot-operated servo module
M3
ICF with two modules
Function Module Type Can be installed in these locations
ICFE/ICFA
Solenoid valve module M1
ICFE20H Solenoid valve module M1*
ICFO Manual opening module M2
ICFB Blank top cover M1 M2
ICFW Welding module M1 M2
ICFC Check valve module M2
ICFC 20P1 Check valve module M2
ICFN 20 Stop & check valve module M2
ICFR Manual regulating valve module M1 M2
ICM Motor valve module M1
ICFD 20 Defrost module M2
ICFS Shut-o valve module M1 M2
ICFF Strainer module M2
ICM Motor operated valve module M1
*)
*)
Module location (fig. 9a, 9b, 9c)
Use only original Danfoss parts, including O-rings and gaskets for replacement.
Materials of new parts are certified for the relevant refrigerant.
In cases of doubt, please contact Danfoss.
