Danfoss RET2001RF - Page 65

Danfoss Climate Solutions AN30483490055001-000103 65
Installation Guide
Fig. 4
RET2001RF/TP5001RF
RX1-S V2
86,0
86,0
28,0
84,0
84,0 30,0
Fig. 5
N
L 230 V ~
1
2 COM
3 NO - ON
4 NC - OFF
ELECTRONICS
Link for
230v
switching
no link for
volt free
switching
